- SPECIFICATION
- DATA SHEET
- PHOTOMETRY
- APPLICATION
-
| Model No. |
Capacity
(W) |
Lighting Resource |
Input Voltage/ Frequency |
Luminous Flux(lm) |
Installation |
Cutout Size
(mm) |
Dimmable |
Beam Angle |
Ra |
IP Grade |
| 6000-6500K |
4000-4500K |
2700-3300K |
| DL00310111 |
1 |
SHARP LED |
DC12V |
100 |
90 |
80 |
Recessed |
¢40 |
Yes |
30°
45°
60°
120° |
83 |
30 |
| DL00310123 |
3 |
250 |
240 |
230 |
| DL00310121 |
1 |
100 |
90 |
80 |
¢33 |
| DL00310123 |
3 |
250 |
240 |
230 |
| DL00310131 |
1 |
100 |
90 |
80 |
¢40 |
| DL00310133 |
3 |
250 |
240 |
230 |
| DL00310411 |
1 |
100 |
90 |
80 |
¢42 |
| DL00310413 |
3 |
250 |
240 |
230 |
| DL00310421 |
1 |
100 |
90 |
80 |
| DL00310423 |
3 |
250 |
240 |
230 |
| DL00310511 |
1 |
100 |
90 |
80 |
| DL00310513 |
3 |
250 |
240 |
230 |
| DL00310601 |
1 |
100 |
90 |
80 |
¢32 |
44 |
| DL00310503 |
3 |
250 |
240 |
230 |
| |
|
|
|
|
|
|
|
|
|
|
|
|
| Features |
|
|
|
|
|
|
|
|
|
|
|
|
| High-quality aluminum and lumisheet acrylic plate, with 90% light transmittance |
| Diffused soft lighting effect |
| Will not fade colors, avoids inventory spoilage |
| Smart,unique design |
| Using integrated heat-dissipation aluminum structure improve the heat dissipation greatly |
| 3 years warranty |
| Emits virtually no UV/IR light in the beam |
| Contains no mercury,Lead and other Toxicants |
| Approved by CE&RoHS |
|
-
| Model No. |
Capacity(W) |
Dimension
(MM) |
Package
(MM) |
Weight |
Carton Size
(MM) |
Quantity Per Carton(pcs) |
Loading Quantity |
| Net(kgs) |
Gross(kgs) |
20'GP |
40'GP |
40'HQ |
| DL00310111 |
1 |
¢50.5* 35 |
60*60*55 |
0.060 |
0.070 |
320*320*250 |
100 |
100000 |
200000 |
220000 |
| DL00310123 |
3 |
| DL00310121 |
1 |
¢41.5* 20 |
| DL00310123 |
3 |
| DL00310131 |
1 |
¢50.5* 35 |
0.075 |
0.085 |
| DL00310133 |
3 |
| DL00310411 |
1 |
¢51.5* 43.9 |
| DL00310413 |
3 |
| DL00310421 |
1 |
¢51.5* 25 |
| DL00310423 |
3 |
| DL00310511 |
1 |
¢51.5* 33.5 |
0.060 |
0.070 |
| DL00310513 |
3 |
| DL00310601 |
1 |
¢41.8* 45.4 |
0.082 |
0.090 |
| DL00310503 |
3 |
| |
|
|
|
|
|
|
|
|
|
|
| Operating Temperature |
-40°C To +55°C |
| Beam Angle |
90°~100° |
| Working Temperature |
<55°C(ambient temperature 15°C) |
| Color Rendering Index(CRI) |
>83 |
| Total Harmonic Distortion |
<9% |
| Materials |
|
|
High-quality Aluminum Alloy Body,lumisheet acrylic plate |
| Working Life |
>50,000hours |
|
-
Ideal for Ceiling light ,Shopping center,Walkway ,Hotel,Restaurant,Entertainment places ,Display case ,Museum ,Household ,Entertainment places . |
|
|
