Addressable High Sensitivity Fire Alarm Smoke Detector With Relay Output

  • SPECIFICATION
  • DATA SHEET
  • PHOTOMETRY
  • APPLICATION
  •  Product Description

    Feature

    1. Easy installation and maintenance.
    2. High sensitivity, high shield.

    3. 4 wire, soud and flash and relay output.



    Technical specification

    Item Describe
    Input voltage DC9~35V
    Static current 500uA(replay N.O.)     12mA(relay N.C.)
    Alarm current 18mA(replay N.O.) 10mA(relay N.C.)
    Alarm indication red LED on
    Operating temperature -10~+50°C
    Humidity 0%~95%RH(No condensation)
    Alarm output sound & flash & relay output
    Contact rating 0.5A@DC28V
    Sensitivity  0.5dB/m(±0.1dB/m)
    Dimension 103*53mm



    Addressable High Sensitivity Fire Alarm Smoke Detector With Relay Output
